Industrial scales

Postal scale for letters and parcels ITC-S2

ITC-S2 is a combined solution for your shipping. This dual-range scale is of stable and compact design and fitted with a double load cell system. Whether you want to weigh parcels of up to 32 kg with 10 g precision or letters, small parcels and shipments with up to 1 gram precision: You benefit from easy, fast and safe handling.
Contact a consultant
The ITC-S2 solution lets you exactly and quickly weigh a broad spectrum of goods shipments. Two integrated load cells make it possible: This all-rounder precisely weighs shipments of up to 3 kg as accurate as 1 g. For shipments from 3 to 32 kg this device automatically switches to the second load cell. Here, the weighing result has an accuracy up to 10 g. This space-saving dual-range scale is also impressive in terms of its sophisticated design: For safe handling the bell-shaped platform is curved. Your advantages: Roll-shaped parcels are fixed during the weighing process, flat shipments can be picked up better. The determined shipment weight can be easily read on a 20 mm 7-segment display. At the same time, the optional second display informs your customers about the weighing result.
Products that may also interest you:
EK-AEP compact scale
The EK-AEP series allows safe measuring in potentially hazardous areas in which flammable substances are produced or processed.

Highlights



  • Dual-range scale 3 kg/32 kg with verifiable scale interval 1 g/10 g
  • Dimensions weighing platform, W x L x H: 350 x 248 x 112 (+10) mm
  • Serial interface for a smooth data exchange
  • Convenient setting of the integrated weighing module via configuration tool
  • Easy and safe handling:
    • Bell-shaped platform curved 4 times for fast removal of letters and safe fixation of round shipments
    • Easy to handle adjustable feet for fast and simple leveling, also for integrated desktop solution
    • Integrated display and operating unit: 7-segment display, digit height: 20 mm; key functions: Switch on/off, zero setting, taring and test
  • External power supply unit for fast and easy replacement when servicing is needed





Product images and technical information may differ and may not be available in your country.

Areas of use

  • For smaller shipping departments and mail rooms for weighing of letters, small packages and shipments

Highlights

  • Dual-range scale 3 kg/32 kg with verifiable scale interval 1 g/10 g
  • Dimensions weighing platform, W x L x H: 350 x 248 x 112 (+10) mm
  • Serial interface for a smooth data exchange
  • Convenient setting of the integrated weighing module via configuration tool
  • Easy and safe handling:
    • Bell-shaped platform curved 4 times for fast removal of letters and safe fixation of round shipments
    • Easy to handle adjustable feet for fast and simple leveling, also for integrated desktop solution
    • Integrated display and operating unit: 7-segment display, digit height: 20 mm; key functions: Switch on/off, zero setting, taring and test
  • External power supply unit for fast and easy replacement when servicing is needed

Product images and technical information may differ and may not be available in your country.

Areas of use

  • For smaller shipping departments and mail rooms for weighing of letters, small packages and shipments

More information, please

How can we help?

We are happy to inform & advise you on your options with this solution or service. Please provide us with some information so that we can assist you in the best possible way. We will get back to you as soon as possible.
Contact a consultant

Details & options

  • Customer display
SpecificationsFactsDetails
Dimensions weighing platformW x L x H: 350 x 248 x 112 mmAdjustable height: +10 mm
Weighing rangesDual-range scale
3 kg/1g
32 kg/10 g		Automatic switching of the scale interval as from 3 kg:
1 g to 10 g
Display7-segment displayDigit height: 20 mm
Keyboard6 keys + ON/OFF key3 keys serve as basic functions: Test, zero setting, recording
IP ratingDevice: IP43Plug-in transformer unit: IP30
Operating temperature-10 °C to +40 °C

Details & options

Specification Facts Details
Voltage variants 230 V
230 V 		50 Hz, AC
50 Hz, AC
Load cell 2x Strain Gauge Single-Point Load Cell
2x Strain Gauge Single-Point Load Cell
Protection class IP30
IP43
IP30
IP43
Maximum load 32kg
32kg
Temperature range 14 °F to 104 °F
-10 °C to +40 °C 		Operation
Installation type Table
freestanding
Table
freestanding
Dimensions of load plate 350 x 248 mm
350 x 248 mm
Keyboard properties 6 Tasten + Ein-/Aus-Taste
6 Tasten + Ein-/Aus-Taste
Dimensions (L x W x H)/(D x W x H) 370 x 339 x 114 mm
370 x 339 x 114 mm
Load receptor 2 DMS-Single-Point-Wägezellen
2 DMS-Single-Point-Wägezellen
Supply medium Plug-in power supply
Plug-in power supply
Display properties 7-segment-LCD-display, digit height 20mm
7-segment-LCD-display, digit height 20mm
Accuracy class III
III
Weighing range 3/32 kg
3/32 kg 		e=1/10 g
e=1/10 g
Material Plastic
anodized aluminum
stainless steel
Plastic
anodized aluminum
stainless steel
Approval information R76 = NAWI, Non automatic weighing instrument
R76 = NAWI, Non automatic weighing instrument
Explosion safety Only ex-free
Only ex-free
