Industrial weighing terminal iS30

With its compact design and a large fully graphic display, this terminal impresses in all application areas
Thanks to its many interfaces and software programs the versatile weighing terminaliS30 covers a wide range of applications for the chemical or pharmaceutical industry,in the food area, logistics or in the metal and electro industry.With the large fully graphic display the operator sees all important process informationat a glance. Product data can be quickly viewed and edited. Thanks to an alphanumerickeyboard data can be effectively entered or deleted. Large keys with mechanicalpressure point allow operation with gloves. An acoustic signal confirms an input.
These products might also interest you:
Compact weighing terminal iS10
Small but powerful: This robust compact weighing terminal stands out in many areas whether it is checking, order picking, packaging, dispatch, documenting or stocktaking.
Compact weighing terminal iS20
Small in size... big on performance. The durable iS20 compact weighing terminal excels in many areas throughout your business: checking, picking, packing, delivering, documenting and taking inventory. It is easy to use and comes in a stainless steel design.
Compact weighing terminal iS25
Versatile functions with little space requirement - Fast data transfer and efficient handling for smooth processes. An example: The visual tolerance check with LED traffic light function is only one of many highlights of the easy to integrate iS25.

Highlights

  • Robust industrial design with IP65 protection
  • Additional IP69 protection for high pressure cleaning in harsh environments
  • Housing as table-top/wall mount version or for control panel mounting
  • VESA 100 mounting option on the back of the housing
  • 5.7" fully graphic display with a 320 x 240 resolution and LED backlighting
  • Fast and exact weight value establishment even in case of time-sensitive applications
  • Four function keys which can be freely assigned and four more application keys for quick input of process data

Product images and technical information may differ and may not be available in your country.

Areas of use

The weighing terminal establishes weight data, controls components such as dosing systems and records all operating data. In addition to weighing functions, it provides programs for the following applications:

  • Counting
  • Dosing
  • Recording of statistical data in compliance with prepack regulations
  • Tolerance Check

Details & Options

Thanks to powerful electronics of the terminal, weight values can be quickly established and data directly transferred to higher ranking systems. Up to two weighing modules may be connected for even more flexibility.

  • Interfaces RS232, RS422, Profibus DP, Profinet IO, USB, Ethernet and 24 I/Os
  • Up to two scale interfaces for connection of analog scales, Pesa scales or precision scales
  • Application programs, program licenses: Weighing, counting, tolerance control, statistics, single-component filling, dynamic calibration, in-motion weighing, recording database, data input devices, data output devices, field bus
  • Battery pack with charger and battery holder
  • Various measuring and data cables
  • Column, protective cover
Specification Facts Details
Voltage variants 100 - 240 V
24 V
akku 		50 - 60 Hz, AC
DC
AC/DC
Verificationable ☑
Protection class IP65
IP69
Interfaces I/O Signals
WLAN
Profibus
Profinet-IO
RS232
RS422
Analog output
Ethernet
Temperature range 14 °F to 104 °F Operation
Installation type Panel Mounting
Table
Pedestal
Wall
VESA-100 installation possibility
Dimensions (L x W x H)/(D x W x H) 99 x 300 x 230 mm
Operating system Windows CE
Weight 13.2 lbs
Software-Applications weighing
counting
tolerance control
statistics
one-component dosing
Supply medium 3 m power cord with safety plug
Display properties fully graphic colour display
Accuracy class III
II
Weighing range depending on load receptor
Material Stainless steel 1.4301
Display resolution 320 x 240
Scale connections analogous
precision scales RS232
pesa
Explosion safety Only ex-free
For take away

Downloads

You can find operating instructions, software updates, licenses, service requests for your personal device in the Bizerba customer portal.
Factsheet iS30 (167 KB)
Datasheet iS30 (712 KB)
