Industrial Floor Scales

Load receptor iL Professional 7500F/MP

Multi point load receptor in extra flat design
The simple and robust structure of the electromechanical load receptors guarantees low maintenance and wear-resistant operation with a high level of long-term precision. The load receptors of the iL Professional F/MP series can be optionally used: built-in or freestanding, s/s lacquered deep black or made of s/s. Perfectly suitable for many applications.Despite the large number of options that the modular component system affords, all load carriers are available as standard products.

Highlights

  • Load cell protection: IP67 / IP68
  • Load receptor with load cells in EEx ib-design also approved for the Ex-area in zone 1
  • Low overall height of weighing platform, 85 mm to 128 mm
  • Modular components for your perfectly customized load receptor

Product images and technical information may differ and may not be available in your country.

Areas of Use

  • Load receptor with different load cell type as single or dual interval scale or dual range scale for weighing ranges of from 1500 kg to 6000 kg, for dry and wet areas in the warehouse, goods receiving and production
  • in combination with Bizerba weighing terminals it can be used for counting, dosing, formulation, checking and commissioning
  • for hazardous areas classified as zones 1/21 and 2/22 (optional)

Details & Options

SpecificationFactsDetails
Load cell SB4
Verificationable
Protection class IP68
Maximum load 6000kg
Temperature range -50 °C to +85 °C
-10 °C to +40 °C
Storage
Operation
Installation type freestanding
Built-in
Dimensions (L x W x H)/(D x W x H) 1500 x 1250 x 128+6 mm
2000 x 1500 x 128+6 mm
1500 x 1500 x 128+6 mm
Weight 256 - 376 kg
Load receptor SB4
Supply medium Supply by weighing terminal
Mains connection 100 - 240 V, 50/60 Hz
Accuracy class III
Weighing range 3000/6000 kg
3000/6000 kg
1500/3000 kg
3000 kg
1500/3000 kg
6000 kg
3000 kg
1500 kg
1500 kg
6000 kg
d=1/2 kg
e=1/2 kg
d=0,5/1 kg
d=1 kg
e=0,5/1 kg
d=2 kg
e=1 kg
d=0,5 kg
e=0,5 kg
e=2 kg
Material painted steel
Galvanized steel
Stainless steel V2A
Ramps
Load plate version Screwed
Withdrawable
Approval information R61 = AGFI, Automatic grafimetric filling instrument
Wheel load 2000 kg
Axle load 4000 kg
Explosion safety ATEX Zone 1/21
ATEX Zone 2/22
